Fossil algae, dating from 541 million years ago, offer new insights into the plant kingdom's roots

""
At left, the external surface of Protocodium sinense. Middle, the view through the outer layer made up of utricles. At right, the central siphons (photo by Cédric Aria)

Paleontologists have identified a new genus and species of algae called Protocodium sinense that predates the origin of land plants and modern animals and provides new insight into the early diversification of the plant kingdom.

Discovered at a site in China, the 541-million-year-old fossil is the first and oldest green alga from this era to be preserved in three dimensions, enabling the researchers to investigate its internal structure and identify the new specimen with unprecedented accuracy.

The study was published this week in BMC Biology, opening a window into a world of evolutionary puzzles that scientists are just beginning to unravel.

Reconstruction of a cross-section through Protocodium sinense, showing likeness to modern Codium (illustration by Shu Chai)

Protocodium belongs to a known lineage of green algae and has a surprisingly modern architecture, showing that these algae were already well diversified before the end of the Ediacaran period,” says co-author Cédric Aria, a post-doctoral researcher in the University of Toronto’s department of ecology and evolutionary biology in the Faculty of Arts & Science who is based at the Royal Ontario Museum (ROM).

“Its discovery touches the origin of the entire plant kingdom and puts a familiar name on the organisms that preceded the Cambrian explosion over half a billion years ago, when the world’s first modern ecosystems emerged.”

The newly discovered Protocodium fossils were found by a team led by Hong Hua, a geology professor, and post-doctoral researcher Shu Chai – both of Northwest University in Xi’an, China. It is part of the Gaojiashan biota, the name given to a significant group of exceptionally well-preserved fossils, at the Dengying Formation in Shaanxi Province. In the past 20 years, this geological formation has yielded important fossil species documenting the end of the Ediacaran Period 541-million-years ago.

Simplified phylogeny or tree of life showing the relation of Protocodium and other green algae, known as chlorophytes, to other major lineages of plants (illustration by Cédric Aria)

Organisms and their parts that do not originally absorb minerals – unlike shells or bones – require exceptional conditions to be preserved. In this case, the whole fossils and their fine cellular details were preserved in three dimensions due to the replacement of the original organic material by phosphate. This mode of preservation allowed the researchers to use various electron and X-ray microscopy techniques to virtually slice the fossil, unveil its internal structure with precision and ultimately identify it as a close relative of the modern Codium alga, a type of seaweed.

Protocodium fossils are small spheres half a millimetre wide, about the size of large grains of pollen, covered by a multitude of smaller domes. Thanks to the 3D examination, the researchers determined the domed surface to be part of a complex, single cell that contains thin strands called siphons. This morphology is typical of certain modern single-celled seaweeds that contain many nuclei.

The discovery of Protocodium would call for caution when identifying generic spherical Ediacaran fossils and may imply that organisms like Codium are in fact much older and widespread. The famous Doushantuo fossil embryos, also from China and preserved in 3D, have been at the heart of debates about the deep origin of certain animal groups. Specific stages of some of these animal-like embryos resemble the unicellular Protocodium on the outside, but 3D slicing reveals how they are composed of many cells. On the other hand, numerous 2D, round fossils of uncertain algal or other affinity are also known from the Ediacaran and older periods, but in less detail.

“We know that seaweed-like fossils are at least one billion-years-old,” says Chai, the study’s first author. “But until now, flat, grainy two-dimensional preservation has made it challenging to recognize more than general morphological structures.”

Images of Protocodium sinense using electron microscopy (A) and X-ray computed tomography (B-D). Panels B-D reveal the internal structure (image by Shu Chai, Cédric Aria and Hong Hua)

Green algae are photosynthetic organisms, which means they convert light and carbon dioxide into sugars and oxygen. They were therefore likely important foundations of Earth’s early ecosystems, and the study suggests green algae were already established in the world’s shallow waters as CO2 recyclers and oxygen producers before the Cambrian explosion.

Apart from its smaller size, Protocodium appears surprisingly identical to the modern Codium, a type of green algae found in many seas worldwide. Certain types of this seaweed are notoriously invasive – such as Codium fragile subspecies tomentosoides, dubbed “dead man’s fingers” for its appearance and spread along with commercially farmed shellfish. From an evolutionary perspective, green algae like the ancient Protocodium and land plants share a common ancestor that was thought to be about one billion to one billion and a half years old – but is now likely older since the assignment of Protocodium so close to a modern group pushes back in time the history of the entire plant kingdom.

“It’s very telling that such an organism has remained practically unchanged over at least 540 million years,” says Aria. “By the Ediacaran, evolution had driven it towards a stable adaptive zone – it’s been comfortable there since and, more than that, quite successful – so much so, in fact, that nowadays Codium takes advantage of global trade to easily outcompete other algal species.”

Funding support for the research and field work came from the National Natural Science Foundation of China and the National Key Research and Development Program. Aria’s post-doctoral fellowship is funded via the Polk Milstein Family Trust Fund (ROM) and the Natural Sciences and Engineering Research Council of Canada
